JFT - jb Capacitors
| Capacitor Class | “X1” stands for X1 class |  |
|---|---|---|
| Climatic Category | 55/ 105/ 21 | |
| Operating Temperature Range | -55°C~ +105°C (for which the capacitor can be operated continuously at rated voltage. |
|
| Rated Voltage | 300V.AC | |
| Capacitance Range | 0.0022 ~ 4.7μF | |
| Capacitance Tolerance | ±10% | |
| Insulation Resistance | (I.R.) >=15,000 MOhm (C<=0.33μF) >=5,000 MOhm (C>0.33μF) |
|
| Dissipation Factor | (DF) 0.001 (0.1%)max. at 1KHz |
- This specifications cover the requirements of jb Metallized Polypropylene
- Film AC Capacitor (Interference Suppressors Class-X1)
